Superwinch Utility Trailer S7500SR Winch - 7,500 lbs. Pull Rating, 60 ft. Synthetic Rope
Superwinch S7500SR – The Trailer Winching Powerhouse
The S7500SR Winch reinforces Superwinch’s legacy as the go-to brand for trailer-specific winching solutions. Designed to handle tough trailer pulls with ease, the S7500SR delivers 7,500 lbs. of pulling power, thanks to a robust 3.6 HP permanent-magnet motor and an all-steel 3-stage planetary gear system.
Key Features:
-
7,500 lb Rated Line Pull – Built to handle the demands of heavy-duty trailer applications
-
Powerful 3.6 HP Motor – Delivers consistent, reliable performance
-
3-Stage Planetary Gearbox – Ensures smooth, efficient operation
-
Synthetic Rope – Lightweight, strong, and safer under load
-
Safety-Tinted Protective Cover – Shields the operator and drum from debris and moving parts
-
Foot-Operable Free-Spool Lever – Machined aluminum lever allows hands-free engagement
Whether you're loading vehicles, equipment, or gear, the S7500SR is engineered to make the job safer, faster, and more efficient
Features
| Category | Details |
|---|---|
| Rated Line Pull | 7,500 lbs |
| Motor | 3.6 HP Permanent Magnet Motor (Provides Dynamic Braking) |
| Gear System | 3-Stage Planetary |
| Gear Ratio | 159:1 |
| Solenoid | Sealed |
| Clutch Type | Lever Style Freespool (Hand or Foot Operation) |
| Gears | Steel Cut Gears (Enhanced Engagement & Longevity) |
| Brake System | Automatic Load Holding Brake |
| Rope Material | Wire Rope |
| Fairlead | Stainless Steel 2-Way Roller Fairlead |
| Remote Control | 30 ft. Handheld Wired Remote |
Specs
| Category | Details |
|---|---|
| Condition | New |
| Weight | 40 lbs |
| Dimensions (LxWxH) | 22" x 13" x 9" |
| Rated Line Pull | 7,500 lbs |
| Motor | 3.6 HP Permanent Magnet Motor (12V DC) |
| Gear System | 3-Stage Planetary |
| Gear Ratio | 159:1 |
| Clutch | Kick-n-Flip |
| Brake System | Mechanical, Automatic Load Holding (Outside Drum) |
| Rope Type | Synthetic |
| Rope Size | 1/4" x 60 ft (6.35mm x 18.3m) |
| Fairlead | Roller-Coaster Fairlead / Hawse Hybrid |
| Solenoid | VS4 Sealed, Submersible, Vented |
| Winch Hook | Heavy-Duty, Clevis Pinned, Latched |
| Remote Control | 12 ft Rubber Sealed Hand-held Wired Remote |
| Line Speed | 19 FPM @ 80 Amps Motor Draw (5.8 MPM) |
| Winch Series | S Series |
| Winch Type | Electric |
| Surface Finish | Powder Coated |
| Material | Steel |
| Voltage | 12V DC |
| Warranty | 2-Year Limited Manufacturer |
